MS Series

High yield and complete safety for the machine operator.
The derinder/membrane skinner MS is intuitive, easy to use and extremely precise and efficient, with regard to both yield and production capacity.

Save your operator’s hands
Complete safety for the operator thanks to the innovative CLO safety system (available on request) able to prevent any harm to the operator’s hands.
Efficient Sanitation
Modern design with continuous welding and rounded edges to ensure greater hygiene. No parts to be disassembled for cleaning and sanitation operations.
Maximize productivity
High toothroll speed to improve production rates.
Dual Blade version available
MS is also available in Dual Blade version, with the maximum distance of 35 mm between the blades.

Get Offer!

Technical Specifications

Ergonomic working table:
Ergonomic operating height and infeed area to improve product handling and safety.
Different options for superior productivity:
Multiple types of toothroll available (including dual pitch) for specific applications and for greater productivity.
Easy access for mainteinance:
The motor, wiring and mechanical parts can be easily accessed from two side panels.
Robust construction:
Machine base in food-grade non-radioactive stainless steel, and toothroll in special, highly resistant steel for greater durability and constant efficiency over time.
Save time on mechanical adjustments:
The option of the quick blade change minimizes the time needed to change the slicing set (MS475/MS520).

Technical Data

Height (MS475P / MS520 PM / MS600P / MS800P):	960 / 960 / 960 / 1050 mm - 37.8" / 37.8" / 37.8" / 41.5
Width (MS475P / MS520PM / MS600P / MS800P):	835 / 800 / 960 / 1160 mm - 33" / 31.5" / 38" / 46"
Depth :	840 mm - 33"
Weight :	155 / 166 / 166 / 210 KG - 341 / 366 / 366 / 463 lb
Motor power:	0.75 / 1.1 Kw
Working width (MS475P / MS520 PM/ MS600P / MS800P):	475 / 520 / 600 / 800 mm - 18.7" / 20.47" / 23.62" / 31.5"
Air consumption :	270 lt/min
